Homeswitch Metal TYC-50 Double Flat Shaft CW/CCW Undirectional Speed Reduction Synchronous Motor AC110V 15-18RMP Silver
Availability: Pre-Order, Inquiry Price
About this product
*This 110v low rpm motor is made of high-quality materials. Easy to install with great durability.
*Product diameter: 49mm/1.93inch; Product height:40mm/1.56inch; Weight:88g
*Voltage: AC 110V; Speed:15-18rpm; Torque:1.5KGF.CM; Current: 20-100mA; Power: ≤ 4W
*Direction of rotation: no orientation (CW/CCW will automatically reverse when encountering large resistance) It is small power consumption, torque, low noise, small size, light weight and easy to use.
*Rotating motor are widely use in many place such as hand-made DIY project, electric fan, heaters, Christmas tree, air conditioners, microwave ovens, rotating lamps, electric tables, electric models, electric shelves, dishwashers, curtain machines, popcorn machine, etc.
Description
Features:
1.Direction of rotation: no orientation (CW/CCW will automatically reverse when encountering large resistance).
2.It is small power consumption, torque, low noise, small size, light weight, easy to use.
3.The synchronous motor and the slowdown in one body can control the pros and cons of the synchronous motor.
4.Wide applicaions:good synchronous motor for hand-made,model such as heater machine,electric fan,air conditioner,popcorn machine,etc.
Specifications:
Material: Metal
Color: Silver
Brand name: Homeswitch
Voltage: AC 110V
Speed:15-18rpm
Torque:1.5KGF.CM
Current: 20-100mA
Power: ? 4W
Upper internal thread: M3
Shaft length: 15.5mm
Shaft diameter: 7mm
Flat shaft thickness: 5mm
The connecting cable is about 40cm long.
Flat shaft part height: 8mm
Product diameter: 49mm/1.93inch
Product height:40mm/1.56inch
Weight:88g
Package include:
1 x Synchronous Motor
