GEPRC GR2306.5 Brushless Motors for FPV Racing Drone Quadcopter (1850KV, 1pcs)
Availability: Pre-Order, Inquiry Price
About this product
*Package Dimensions : 12.68 x 2.2 x 1.97 inches; 1.83 Ounces
*Item model number : GR2306.5
*Date First Available : October 16, 2021
*Manufacturer : GEPRC
Description
Specifications:
Item name:GR2306.5 Motors
KV:1350KV / 1850KV / 2450KV (Optional)
Configuration:12N14P
Stator Diamter:23mm
Stator Length:6.5mm
Shaft Diameter:4mm(Hollow)
Motor (Dimension(Dia.*Len)): ?28.2*29.2mm
Idle current(10)@10V(A):1.95
of Cells(Lipo):4~5S
Max Continuous (Power(W)15S):1000
Internal Resistance:38m?
Max Current(15S):49A
Effciency Current:(3-7A)>85%
Rotor: N52H arc magnets
Bearings:JAPAN ISC
Base casing: Al 7075
Wire AWG: 20AWG
Weight(g):31g (not include wire)
Package included:
1x GEPRC GR2306.5 Motor
1x GEPRC M5 Aluminum Lock Nut
4x M3x7 Button head screws
4x M3x8 Button head screws
