PWM dc Motor Speed Controller max 60A CW CCW Digital Display 0~100% Adjustable Drive Module Input 10V~55V

PWM dc Motor Speed Controller max 60A CW CCW Digital Display 0~100% Adjustable Drive Module Input 10V~55V

Name: PWM dc Motor Speed Controller max 60A CW CCW Digital Display 0~100% Adjustable Drive Module Input 10V~55V
SKU: MM28175
Availability: InStock

Product Code: MM28175
Availability: Pre-Order, Inquiry Price

US$0.00

- +

For Bulk Order, Get Better Price.

About this product

*PWM dc motor speed controller max 60A CW CCW digital display 0~100% adjustable drive module Input 10V~55V

*Date First Available ‏ : ‎ January 17, 2022

*Manufacturer ‏ : ‎ CozParts

Description

The PWM controller must be loaded with equipment in order to work properly. Please do not test without load.

Digital display PWM DC motor speed controller display 0~100% for speed

working voltage range:10V - 55V

output voltage:Linear (under load)

Rated current:40A

Speed control range:0%——100% digital display

Maximum current:60A

Control frequency:15KHZ

size:100mm
*90
mm
*45
mm

apply to :DC brush motor/brush fan /led
